名称Project name | Model MX-6HG | ModelMX-8HG |
工作台面积 Table area |
1372x330mm | 1524x360mm |
纵向行程(左右X方向) Longitudinal travel (left and right X direction) |
1020mm | 1200mm |
横向行程(前后Y方向) Transverse stroke (front and rear Y direction) |
400mm | 500mm |
垂向行程(上下Z方向) Vertical stroke (upper and lower Z direction) |
380mm | 500mm |
工作台载重 Table load |
500KG | 900KG |
主轴端面到工作台距离 Spindle end face to worktable distance |
470mm | 660mm |
主电机功率 Main motor power |
5HP | 5HP |
电压 Voltage |
三相380v(或220V/415V/440v) | 三相380v(或220V/415V/440v) |
频率 Frequency |
50/60Hz | 50/60Hz |
主轴锥孔 Taper hole of spindle |
NT40主轴 | NT40主轴 |
主轴级速 Spindle stage speed |
16 | 16 |
低速 Low speed(rpm) |
80/135/210/325/660/1110/1750/2720 | 80/135/210/325/660/1110/1750/2720 |
高速 High speed(rpm) |
160/270/420/650/1320/2220/3500/5440 | 160/270/420/650/1320/2220/3500/5440 |
主轴行程 Travel of spindle |
120mm | 120mm |
套筒 Jacket |
105mm | 105mm |
T型槽 T-groove |
16x3x65mm | 16x3x65mm |
滑枕伸出臂 Sliding pillow outstretched arm |
600mm | 600mm |
机床外形尺寸 Machine tool shape dimension |
1800/1700/2000mm | 2500/2600/3000mm |
重量 Weight |
1900KG | 3000KG |
Milling machine Model M8H | ||
Machine tool accessories | Standard configuration | Optional configuration |
Spring chuck | NT40 Machine tool chuck | There are no optional items |
Precision flat pliers | 6 inches Opening Vice |
3 inches Opening Vice 4 inches Opening Vice 5inches Opening Vice 6 inches Opening Vice 7/.5 inches Opening Vice 8 inches Opening Vice |
Combined pressing plate | M12 58 piece suit |
M12 36 piece suit M12 42 piece suit M12 58 piece suit |
Grating ruler |
X Grating ruler Y Grating ruler Two axis digital display meter |
X Grating ruler Y Grating ruler Z Grating ruler Three axis digital display meter |
Power feed ,table feed (Cannot select two types at the same time) |
Do not install any power feed | |
Mechanical power feed in X axis Mechanical power feed in Y axis |
Mechanical power feed in X axis only Do not install any power feed |
|
Drill chuck | 0.5-16mm | There are no optional items |
Chip guard Protective cover |
It has been installed on the workbench | |
Adjusting pad iron | 6 pad irons, & 6 adjusting screws | |
Cooling water pump | Water pump,Water pipe,Water baffle |
Not sure which model the machine is suitable for? Or problems that can't be solved? Pls send email to us, E-mail:service@alsgs.com There will be professional technical personnel to provide technical support.
