Vertical Milling machine

M6H Milling machine

The wider worktable saddle makes the workpiece more stable significantly improves the cutting force and product accuracy and has a fixed screw seat structure..
+: +:
Product Details


名称Project name Model MX-6HG ModelMX-8HG
工作台面积
Table area
1372x330mm 1524x360mm
纵向行程(左右X方向)
Longitudinal travel (left and right X direction)
1020mm 1200mm
横向行程(前后Y方向)
Transverse stroke (front and rear Y direction)
400mm 500mm
垂向行程(上下Z方向)
Vertical stroke (upper and lower Z direction)
380mm 500mm
工作台载重
Table load
500KG 900KG
主轴端面到工作台距离
Spindle end face to worktable distance
470mm 660mm
主电机功率
Main motor power
5HP 5HP
电压
Voltage
三相380v(或220V/415V/440v) 三相380v(或220V/415V/440v)
频率
Frequency
50/60Hz 50/60Hz
主轴锥孔
Taper hole of spindle
NT40主轴 NT40主轴
主轴级速
Spindle stage speed
16 16
低速
Low speed(rpm)
80/135/210/325/660/1110/1750/2720 80/135/210/325/660/1110/1750/2720
高速
High speed(rpm)
160/270/420/650/1320/2220/3500/5440 160/270/420/650/1320/2220/3500/5440
主轴行程
Travel of spindle
120mm 120mm
套筒
Jacket
105mm 105mm
T型槽
T-groove
16x3x65mm 16x3x65mm
滑枕伸出臂
Sliding pillow outstretched arm
600mm 600mm
机床外形尺寸
Machine tool shape dimension
1800/1700/2000mm 2500/2600/3000mm
重量
Weight
1900KG 3000KG






Milling machine Model M6H
Machine tool accessories Standard configuration Optional configuration
Spring chuck NT40 Machine tool chuck There are no optional items
Precision flat pliers 6 inches Opening Vice 3 inches Opening Vice
4 inches Opening Vice
5inches Opening Vice
6 inches Opening Vice
7/.5 inches Opening Vice
8 inches Opening Vice
Combined pressing plate M12 58 piece suit M12 36 piece suit
M12 42 piece suit
M12 58 piece suit
Grating ruler X Grating ruler
Y Grating ruler
Two axis digital display meter
X Grating ruler
Y Grating ruler
Z Grating ruler
Three axis digital display meter
Power feed ,table feed
(Cannot select two types at the same time)
  Do not install any power feed
Mechanical power feed in X axis
Mechanical power feed in Y axis
Mechanical power feed in X axis only
Do not install any power feed
Drill chuck 0.5-16mm There are no optional items
Chip guard
Protective cover
It has been installed on the workbench
Adjusting pad iron 4 pad irons, & 4 adjusting screws
Cooling water pump Water pump,Water pipe,Water baffle
