Which model of ALSGS table feed I am using?

From:ALSGS2021-05-16

Which model of ALSGS table feed I am using?

Some customers have trouble with the table feed （power feed） of milling machines and need to buy accessories,
Some customers need to buy table feed （power feed） of milling machines again to increase equipment,
But don't know which model of ALSGS table feed （power feed） is being used?

The picture shows the turret milling machine with three table feed （power feed）,

The letter Z is attached at the end of the table feed （power feed） which moves up and down on the z-axis pulling saddle.

The letter Y is attached at the end of the table feed （power feed） that moves back and forth by pulling the saddle on the y-axis.

The letter X is attached at the end of the table feed （power feed） which is installed on the x-axis to pull the table to move left and right.

The three table feed （power feed） from left to right are AL-510sz (110V), Al-310sy (110V) and Al-310sx (110V).

Because there is only one type of table feed （power feed） installed on the Z-axis of the milling machine table: AL-510sz, only AL-510sz can be selected for this position.

For the y-axis table feed （power feed） installed on the milling machine table, AL-310sy, Al-410sy and Al-510sy can be selected, and their installation dimensions are the same.

The table feed （power feed） installed on the x-axis of the milling table can be Al-310sx, Al-410sx and Al-510sx, and their installation dimensions are the same.

Because of their different power, customers can choose different power table feed （power feed） according to their own needs.
